Table Top Weighing Scale

Product Description

We are one of the best manufacturer and supplier of heavy duty Table Top Weighing Scale which can be used to measure the weight of medium to heavy weight loaded or unloaded vehicles. It is designed by our team of skilled professionals by using highly calibrated equipment and engineering class materials which results in higher accuracy and strength to measure and withstand heavy loads. Table Top Weighing Scale offered by us is digital display mounted on a vertical steel pole which gives output in different units.

Main Feature

• AC/DC Power Supply Standard chargeable battery.
• 7-bits 0.8inch LED Display, 3 Level Battery indicators.
• Able to setup zero tracking range, zero range.
• With 2-point calibration correction function, 2 Compensation calibration methods.
• Able to save 1001 weighing records, 1000 truck records consisting of truck ID and corresponding tare weight 201 records of goods.
• Able to print across and upright weighing bill.
• Able to print different statistical reports.
• Standard RS232 communications interface Standard Score board interface with current loop.
• Standard parallel print interface. Able to connect assigned thermal printer.

Other Details

• A/D Conversion method 2-A.
• Input signal range : -16mV to 18mV.
• A/D Conversion speed: 10times/sec
• A/D Conversion ode: 1million code.
• Loadcell excitation DC SV.
• Max connection number of load cell: 8at 3500/16 at 7000
• Loadcell connection mode: 6 wire auto compensation
• for long distance.
• Division: 1/2/5/10/20/50/100 Optional
• Clock: real clock without effect when power off.
• Transmission: Current loop/RS232 signal.
• Baud Rate: 600
• Transmission distance <30meters
• Serial communication interface.
• Transmission method RS232/RS422/RS485
• Baud Rate: 600/1200/2400/4800/9600
• Standard parallel output interface.
• Power Supply AC220V or DC6V, 10Ah External
• rechargeable battery.
• Platform Size: 1m x 1m, 2m x 2m, 3m x 3m
• Capacity: 1t, 2t, 3t, 5t, 10t

Capacity:

• 3kg &5kg/1g
• 15kg & 30kg / 5g
• 60kg & 100kg / 10g
• 150kg & 200kg / 50g
• 300kg & 400kg / 100g
• 500kg & 3000kg / 200g

Pan Size:

• 190x2/75mm
• 300 x 340mm
• 310x 410mm
• 410x510mm
• 1000 x 1000mm
• 3000 x 3000mm
